PCB

10 Layers

CPU

Soldered down Intel Core i3/i5/i7/Celeron Processor

2C4T/4C8T

4M/6M/8M Cache

TDP 15W

RAM

2*SO-DIMM DDR4, Max.64GB

Graphics Card

IntelUHD Graphics

SATA

1*SATA CONN

1*M.2 Key M Slot

Audio card

Realtek ALC256

Network Card

1*Realtek 8111H

10/100/1000 Base-Tx Gbe Compatible

Onboard Intel Harrison Peak WiFi6 AX201 and BT5.1

Display

1*HDMI 2.0，Supports 4K@60HMz

1*DP 1.4 Via USB-C

Expansion Slot

1*M.2 Key M，Supports 2242、2280 SATA/ 2280 NVME SSD

Front Panel I/O

1*USB3.1 GEN1 Type-A

1*USB3.1 GEN1 Type-C

1*AUDIO

1*PWR_BTN

Rear Panel I/O

1*DC_IN

1*HDMI 2.0b

2*USB 3.1 GEN1 Type-A

1*RJ45

1*USB-C

Internal I/O

1*F_USB( 2*USB 2.0 Via internal headers)

1*F_Panel

1*SATA 3.0

1*SATA_PWR

1*CPU_FAN PWR

1*M.2 Key M

OS Information

Win 10-64bit/Android/Chrome

Operating Temperature

-15℃-60℃

Operating Humidity

0%-95% Relative Humidity，Non-condensing

Dimension

100mm*100mm

Power Supply

19V/65W
